Product Details:
|
| Top Skin: | Ceramic, Porcelain | Backing Panel: | 5-21mm Aluminum Honeycomb Panel |
|---|---|---|---|
| Thickness: | 8-30mm | Maximum Panel Size: | 1500*3000mm |
| Adhesive: | 2-Component Expoxy Resin | Surface Treatment: | Anodized, Brushed, Foil Decoration, Mirror, PE Coated, Printing, P |
| Edge Processing: | Edge Closed, Edge Open, 45 Degree Closed | Usage: | Outdoor,Wall Cladding |
| High Light: | Eco Friendly Porcelain Honeycomb Panels,Fireproof Porcelain Honeycomb Panels |
||
Ceramic Tile Porcelain Honeycomb Composite Panel for Floor & Wall Panel
WDF provides thin, quality, eco-friendly porcelain slabs and tiles applied on Honeycomb panels. Brilliant large-cut 3, 3+, 5 and 6mm porcelain and our honeycomb backing provides a durable surface with a simple installation process.
Panel Composition
| Structure | Face finish | 3-6mm Porcelain sheet/natural stone veneer |
| Adhesive | epoxy resin | |
| Substrate panels | Aluminum honeycomb panel,fiberglass honeycomb panel | |
| Honeycomb core material | Aluminum honeycomb (1/4”,3/8”cell size, aluminum foil 0.04 to 0.08mm) | |
| Specification | Standard thickness(mm) | 15mm,20mm,25mm,30mm etc |
| Max size( marble) | 1500*3000mm | |
| Max size( granite) | 1200*2400mm | |
| Edge design | Open/close/solid ( on your request ) | |
Advantages
Manmade, with many colors and textures to choose from which is not only pleasing to the eye, but also much more eco-friendly than stone. Our large, cut to order pieces of porcelain provides the aesthetic appeal and strength as well as:
Application
Table Top
Furniture
Wall
Elevator
Why choose ceramic porcelain honeycomb panels?
Taking sheets of porcelain veneer (between 3-6mm thick) and vacuum bonding to our uncompromising and strong honeycomb panel, we have designed an ultra-lightweight panel that can be instantly installed, that are extraordinarily durable and have an unmatched choice for interior or exterior cladding.
| Suggestion: | |
| 1. For interior wall : 15/20mm (stone: 5mm); mostly use marble & travertine; surface treatment: polished/matt surface | |
| 2. For exterior wall:25/28/30mm (stone:8mm); mostly use granite & marble with dark color; surface treatment: polished/matt surface for marble | |
Package Details
WDF uses standard export packages--wooden crate which will largely protect the products well during land/sea/air/train transportation.
Customized package requirements are available.
