Wood Grain Honeycomb Ceiling Panels Rigidity Aluminum Corrugated Composite Panel

Wood Grain Honeycomb Ceiling Panels Rigidity Aluminum Corrugated Composite Panel

Wood Grain Honeycomb Ceiling Panels

Aluminum Corrugated Honeycomb Ceiling Panels

Rigidity Aluminum Corrugated Composite Panel

Place of Origin:

Foshan,Guangdong China

Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Surface Finish:
PVDF/PE/Powder Coating, Anodizing
Solid/Metallic Colors, Wood/Marble/Granite Colors
6mm, 10mm, 12mm, 15mm, 20mm Or Customized Made
600*600mm, 1220*2440mm, Customized Made
Corrugated Core T:
0.15mm, 0.2mm, 0.5mm Or Customized Made
Fire Resistance:
A Grade
Payment & Shipping Terms
Minimum Order Quantity
20-70 usd per sqm
Packaging Details
protective film+plywood case
Delivery Time
7-20 working days depending on qty
Payment Terms
L/C, T/T, Western Union
Supply Ability
50000 SQM per Month
Product Description

Aluminum Corrugated Composite Honeycomb Ceiling Panel with Wood Grain
Aluminum Corrugated Composite Panel is a high-class building and decorative materials laminated with high-temperature adhesive film and aluminum corrugated core. It is a new, light-weight and ECO building materials. The advantages of Aluminum Corrugated Panel are rigidity, super flatness, good fire-resistance, strong strength.


Production Specification:

Regular Size (W*L*T) 1,220*2,440*6 mm
Max. Size(W*L*T) 1,600*12,000*30 mm
Regular Thickness 4/6/8/10/12/15 mm
Available Thickness 4 - 15 mm
Corrugated Core Thickness 0.2 - 0.5 mm
Regular Surface Treatment PVDF, PE, Powder Coating, Anodized, etc.
Perforation Yes (customized)
Applications Ceiling, Roofing, interior decoration of train, bus, ship, truck body, etc.
Customerization(MTM) Yes (color, surface texture, size, shape, pattern, etc.)


Surface treatment
Powder coating: it is most widely used and environmental friendly way
Roll coating: it can make flower and wooden beautiful pattern come to life with 15 years lifespan.
PVDF: It is the best surface treatment with anti-weather, anti-hit function. Experiment shows that pvdf will not fade in 20 years under harsh rain and sun shining.



1, High stiffness, the flatwise shearing strength is up to 2MPa.
2, Good thermal insulation.As the corrugated core has empty channels between front and back skins, the heat is prevented and reserved in the channels, which will give the building with heat insulation.
3, High flatness.
4, Excellent weather resistance.
5, Recyclable.
6, Easy to be fabricated and installed.
For aluminum sheet: Aluminum Alloy 3003H16-H18
For aluminum corrugated core: Aluminum Alloy 1100H16/H24
Packing and Container Loading
There is protective film on panel surface to prevent the skin from dirty and scratch, the panels will be piled flatly and pack in export grade plywood cases.
Wood Grain Honeycomb Ceiling Panels Rigidity Aluminum Corrugated Composite Panel 0


Q: Are you trading company or manufacturer ?
A: We are manufacturer.


Q: How long is your delivery time?
A: Generally it is 10-15 days if the raw materials are in stock. or it is 30-45 days if the raw materials are not in stock, based on quantity.


Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge yet customers are expected to afford the shipping cost.


Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shipment.

Wood Grain Honeycomb Ceiling Panels Rigidity Aluminum Corrugated Composite Panel 1
